Available for Import

Power cable K9PV... copper with EPR insulation in PVC ng(A)-LS sheathing

Copper Power Cables 1kV

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Power cable with insulation made of high-modular ethylene propylene rubber, designed for transmission and distribution of electrical energy in stationary installations for rated alternating voltage 0,6/1 rated frequency up to 50 Hz. The cable is manufactured for general industrial application and is intended for stationary laying in the air, in closed rooms, in the ground, in cable collectors in group laying, including in explosion hazardous zones when supplied to the domestic market and for export, including countries with tropical climate. Types of climatic execution of cables - UHL, XL and T.

Technical Specifications

Rated AC voltage	1 kV
Material of conductive cores	Copper
Insulation material of conductive cores	High modulus ethylene propylene rubber (HEPR)
Availability of reservations	no
Armor type	not applicable
Outer sheath material (if no armor)	Polyvinylchloride plastic with reduced fire hazard and low smoke and gas emission (PVC LS / PVC LS)
Material of protective hose (if armor is available)	Polyvinylchloride plastic with reduced fire hazard and low smoke and gas emission (PVC LS / PVC LS)
Availability of metal screen	Yes; no
Fire hazard class	P1b.8.2.2.2.2.
Cable cross-sectional shape	Round
Design of conductor core(s)	Single-wire round (ok); multiwire round (mc); multiwire sector (ms)
Nominal cross-section of conductive cores	1000 mm2
Number of conductive cores	1...5
Number of conductive cores	1...5
Nominal cross-section of conductive cores	1000 mm2
Rated AC voltage	1 kV
Mark	?9?????(?)-LS; ?9??????(?)-LS
Cable shape	Round
Core material	Copper
Insulation material	High modulus ethylene propylene rubber (HEPR)
Sheath material	Polyvinylchloride plastic with reduced fire hazard and low smoke and gas emission (PVC LS / PVC LS)

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
