Available for Import
Power cable K9PV... copper with EPR insulation, armoured in PE jacket
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Description
Power cable with insulation made of high-modular ethylene propylene rubber, designed for transmission and distribution of electrical energy in stationary installations for rated alternating voltage of 0,6/1 rated frequency up to 50 Hz. The cable is manufactured for general industrial application and is intended for stationary laying in the air, in enclosed spaces, in the ground, in cable collectors for single laying, including in explosive zones when supplied to the domestic market and for export, including countries with tropical climate. Types of climatic execution of cables - UHL, XL and T.
Specifications
Rated AC voltage
1 kV
Material of conductive cores
Copper
Insulation material of conductive cores
High modulus ethylene propylene rubber (HEPR)
Availability of reservations
Armoured glass
Armor type
Armor made of aluminum or aluminum alloy wires (AK); Armor made of round galvanized steel wires (SK); Armor made of aluminum or aluminum alloy bands (AB); Armor made of galvanized steel bands (SB)
Outer sheath material (if no armor)
Polyethylene (PE / PE)
Material of protective hose (if armor is available)
Polyethylene (PE / PE)
Availability of metal screen
Yes; no
Fire hazard class
?2.8.2.5.4
Cable cross-sectional shape
Round
Design of conductor core(s)
Single-wire round (ok); multiwire round (mc); multiwire sector (ms)
Nominal cross-section of conductive cores
1000 mm2
Number of conductive cores
1...5
Number of conductive cores
1...5
Nominal cross-section of conductive cores
1000 mm2
Rated AC voltage
1 kV
Mark
K9RVSBP; K9RVSKP; K9RVABP; K9RVACP; K9RVSKBP; K9RVACBP; K9RVESKP; K9RVEACP; K9RVSBPu; K9RVSKPu; K9RVABPu; K9RVACPu; K9RVACBPu; K9RVACBPu; K9RVESKPu; K9RVEACPu; K9RVEACPu.
Cable shape
Round
Core material
Copper
Insulation material
High modulus ethylene propylene rubber (HEPR)
Sheath material
Polyethylene (PE / PE)
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
