Numerically controlled winding machine model ??703651?4.01.00.000
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
materials, by continuous winding on the outer surface of mandrels of type
"cylinder", "truncated cone" type mandrels of carbon-, glass-, organofibre materials and
unidirectional prepregs by the method of "dry" winding
Technical Specifications
| SYSTEM OF AUTOMATIC CONTROL OF TECHNOLOGICAL PARAMETERS | Automated system of control and regulation of technological parameters (ASCRTP) is a system of data collection and processing to maintain (stabilise) the main winding parameters within specified limits, set variables and logging |
|---|---|
| Control system | The machine is equipped with a Numerical Control System. Sinumerik 840D Sl with the corresponding Siemens integrated equipment or Fanuc 0i-TF Plus with the corresponding Fanuc integrated equipment (upon agreement). |
| Total machine layout | In its layout the machine is similar to the lathe. |
| Mains voltages | 380 V |
| Current frequency | SBVVBG |
| Type of mains current | Variable three-phase |
| Diameter of mandrel trunnions | 20...200 mm |
| Workpiece thickness | 40 mm |
| Maximum mass of the product to be wound with mandrel | 2500 kg |
| Method of mandrel fastening | In two poles |
| Seating diameter of belt feeder (woven prepreg shaft) | 50...70 mm |
| Seating diameter of the ribbon feeder (non-woven prepreg cassette) | 48 mm |
| Dimensions of manufactured products | 2000 mm |
| General information | The machine is a technological complex consisting of: a multi-axis machine tool with CNC and a functional module for control of regulation and recording of technological parameters in real time mode. The multi-axis machine tool consists of two standing mac |
| Rolling roller heating temperature | 150 °C |
| Woven fabric rolling force | 300kgs |
| Spindle speed | 0...20 |
| Accuracy of tape laying | +-0.5 mm |
| Material thickness | 0.1...2 mm |
| Width of materials to be installed | 6...300 mm |
| Tension force of woven materials | 10-200 |
| Machine dimensions without electrical cabinets | 3000...6000 mm |
| Dimensions of manufactured products | 1500...100 mm |
| Fundamet | The machine is installed on a concrete foundation and reinforced with foundation bolts, the working drawings of which are developed by the customer on the basis of the technical specification for the foundation attached to the manual. The depth of the foun |
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
