Network Sectioning Point Controller for 6-20 kV Systems (UPS) for Efficient Power Management

Low-Voltage Electrical Panels

Manufacturer: RASU OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The network sectionalisation unit is designed for application on overhead power lines of three-phase alternating current with isolated, compensated or earthed neutral with frequency 50 Hz and 60 Hz of voltage classes 6-20 kV for the purpose of automatic localisation of damaged sections (in case of short-circuit occurrence on these sections), as well as formation of emergency signals about short-circuit current flow on the sections of lines on which it is installed. In addition, the controller performs the functions of network management in normal operation mode (in modes without short circuit) providing operational switching on/off load, the creation of repair schemes, the inclusion of backup sections of the network, creating a network configuration under the conditions of the optimum mode (by supplying an external control signal to the controller through communication channels), disconnection of underloaded or overloaded equipment.

Specifications

Current capacity

Not more than 0.1A

By explosion protection

absent

Degree of protection against external influences

IP51 in terms of protection of the device itself

Length

120 mm

Assignment

Control of 6-20kV network sectionalisation point in normal and emergency modes

Equipment

UPS controller; Data sheet

Mark

RCU-01R (OOPS)

Size; mm

not more than 120×120×120 mm

Material

Various

Modules

not applicable

Type of explosion protection

absent

Width

120 mm

Height

120 mm

Explosion protection

2nd grade

Color

Preferably aluminium

Material of manufacture

Various

Housing material

Aluminum

Degree of protection

IP51 in terms of protection of the device itself

Temperature class

-40..50°?

Climatic version

UHL2.1

Type

6-20 kV Controlled Sectionalisation Point (CSP) controller

Depth

120 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
