Microprocessor Automatic Voltage Regulator AVR-4M 421417.033 for Efficient Power Management

Automatic Control Devices

Manufacturer: ASU-VEI LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The AVR-4M microprocessor-based automatic excitation regulator is designed for use as a part of excitation systems of all types manufactured by Electrosila plant of OJSC Power Machines. The main purpose of the AVR-4M regulator is to regulate voltage at the power plant bus bars, to increase static and dynamic stability limits of synchronous machines, to improve damping of oscillations in the power system. To improve reliability, the regulator is designed to operate in a redundant system.

The regulator performs monitoring and interaction with the excitation system protections. The regulator can be included in the ACS-TP in accordance with the IEC-61850 protocol. The regulator hardware is located in the 6U42HP design.

Warranty period - 36 months from the date of shipment to the factory "Electrosila".

Specifications

Minimum program cycle

0.833

Structure

modular

Hardware platform

ST10

Software platform

Keil

Composition

Controller board, Display and control panel, Interface cell, Generator analogue signal processing cell, Power supply cell, Thyristor converter control cell

Measured frequency range

25...100

Communication speed with I/O modules

500

Number of interfaces RS-485/422/232

1 pcs

Number of Ethernet ports

3 pcs

Number of seats for units

5 pcs

Compatible with modules

DI48, DO32, AI6, AIG, AIE

Maximum switched current

0.3 A

Switching voltage range

220 V

Interface type for communication with I/O modules

CAN

Number of channels

6 pcs

Availability of a memory card slot

Interface type

CAN, USB/RS232, Ethernet

Power supply voltage

24 V

Minimum program cycle, ms

0.833

Type of input signals

analog, discrete

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
