Micromodule A1

Supplies determination of linear acceleration acting along the sensitivity axis of the product and output of information in the form of a digital signal (via SPI interface), the digit capacity of the output signal is 24 bits. Range of linear acceleration determination, m/s2 (g) ± 147 (±15); non-linearity of calibration characteristic 0,3 %; change of conversion coefficient in the operating temperature range ± 1,5 %; change of zero offset in the operating temperature range, m/s2 (g) ± 1 (± 0,1); noise power density, m/(s2.?Hz) (g/?Hz) 1-10-3 (1-10-4); operating temperature range from minus 10 to plus 80 gr.C; bandwidth 300 Hz; data update frequency 600 Hz.
