Linear Suspension Insulator with Protective Shell LC 70/35-I-2 GP Available for Import

Linear Suspension Insulator with Protective Shell LC 70/35-I-2 GP for 35 kV AC Applications

Electrical Insulator Rods
Manufacturer: INSTA LLC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Available Models

Linear suspended rod insulator with protective sheath made of organosilicon composition LK 120/35-I-I-2 GP

Description

Isolators linear suspended polymeric type LK 70/35-I are designed for fixing and isolation of uninsulated and insulated protected wires of SIP-3 type of AC overhead lines with voltage 35 kV with frequency up to 100 Hz at ambient air temperature from minus 60 º? to plus 50 º?. Climatic design and placement category UHL 1 according to GOST 15150. The design of insulators allows mounting of arc protection devices UZD-3 or UZPN directly on the terminations.

Specifications

Rated operating voltage
Built-in memory card slot, support microSD/SDHC/SDXC card (up to 256GB); manual recording/alarm recording kV
Leakage path length
895 mm
Building height
505 mm
Mechanical breaking force in tension, kN
70
