Available for Import

LED Street Light ELMA S 03-250 for Effective Outdoor Illumination

LED Lighting Fixtures

Manufacturer: PROM-SVET LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

ELMA S 03-400 LED luminaire LED luminaire ELMA S 03-300

Description

Series of street LED luminaires for lighting: streets and local roads, neighbourhoods and squares, adjacent and courtyard areas, outdoor areas of industrial facilities. The luminaires meet modern requirements of large customers (including state companies) to energy efficiency, light distribution, form factor and compatibility with control systems.

Specifications

Type of product according to PP RF 616

Lighting fixtures and lighting fittings other than those included in other groupings

Power

250 W

Type of supply current

Upper operating temperature value

SBVVBG °C

Lower operating temperature value

-60 °C

Power supply voltage

100...305 V

Power factor (Pf)

0,98

Protection class against electric current

Luminous flux

27500...50000 lm

Height

369 mm

Width

410 mm

Length

371 mm

Additional options

Inrush current limiting relay, high energy microsecond pulse protection module, NEMA connector, 0-10V dimming interface, PWM, DALI.

Degree of protection against mechanical influences

IK08; IK09

Housing material

Die-cast aluminum alloy

Mounting type

Swivel bracket

Optical element material

Polymethyl methacrylate (PMMA)

Diffuser material

Tempered glass

Climatic execution (according to GOST 15150-69)

UHL1

Color rendering index (CRI)

70;80;90

Double angle half brightness

15;25;30;40;50;55;85;90;120;150;25?105;45?25;95?35;100?30;125?65;155?85

Color temperature

6500 K

Degree of protection against dust and moisture (according to GOST R IEC 60598-1-2011)

IP66

Weight

11,6-12,2 kg

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
