KVVG-P - Control cables with copper conductors, with insulation and sheathing made of polyvinylchloride plasticate, for nominal
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Available Models
KVVG - Control cables with copper conductors, with insulation and sheath made of polyvinylchloride plasticate, for nominal alter
KVVVGng(A) - Control cables with insulation made of PVC plasticate, sheathed in polyvinylchloride plasticate of reduced flammabi
KVVGE - Control cables with copper conductors, with insulation and sheathing made of polyvinylchloride plasticate, shielded, on
Description
Control cables
with copper cores,
with insulation and sheath made of polyvinylchloride plasticate,
for rated alternating voltage up to 660 V with frequency up to 100Hz or direct voltage up to 1000 V
Designed for: laying in premises, channels, tunnels, if the cable is not subjected to significant tensile forces.
Designed for operation at ambient temperature from minus 50 to 50°C and relative air humidity up to 98+2% at 40°C.
Long-term permissible core heating temperature during operation, °? - +70.
Laying of cables without preliminary heating should be carried out at a temperature not lower than minus 15°C. Cables can be laid in the open air on condition of their protection from mechanical damage and direct rays.
Cables can be laid in fire-hazardous premises.
with copper cores,
with insulation and sheath made of polyvinylchloride plasticate,
for rated alternating voltage up to 660 V with frequency up to 100Hz or direct voltage up to 1000 V
Designed for: laying in premises, channels, tunnels, if the cable is not subjected to significant tensile forces.
Designed for operation at ambient temperature from minus 50 to 50°C and relative air humidity up to 98+2% at 40°C.
Long-term permissible core heating temperature during operation, °? - +70.
Laying of cables without preliminary heating should be carried out at a temperature not lower than minus 15°C. Cables can be laid in the open air on condition of their protection from mechanical damage and direct rays.
Cables can be laid in fire-hazardous premises.
Specifications
Material of conductive cores
Copper
Insulation material of conductive cores
Polyvinyl chloride
Sheath material
Polyvinyl chloride
Sheath material
Polyvinyl chloride
Cable shape
Flat
Sheath material
Polyvinyl chloride
Nominal cross-section of conductive cores
0.75...6 mm2
Availability of reservations
no
Number of conductive cores
2...3
Insulation material
Polyvinyl chloride
Insulation material
Polyvinyl chloride
Insulation material
Polyvinyl chloride
Nominal voltage
0.66 V
Core material
Copper
Core cross section
0.75...6 mm2
Nominal voltage
1 V
Core material
Copper
Mark
KVVVG-P
Number of cores
2...3 pc
Mark
KVVVG-P
Design
Single conductor conductor, circular
Core material
Copper
Fire hazard class
?1.8.2.5.4
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
