JunCura series round and rectangular sheathed enclosed busbar with 1.2 kV, rated current 800 to 6300

It is used in AC and DC circuits. three-phase

50 and 60 Hz alternating current with a voltage of up to 1.2 kV and used for

electrical connection of auxiliary transformers with capacity up to 1000 kVA

with panels and cabinets of complete transformer substations used for

electrical connection of exciters with panels, assemblies and panels of the working and

standby excitation of generators with capacity up to 1200 MW and voltage of 825 V at substations

on the underground.

Design:

Current-carrying busbars on removable support insulators are located inside the common aluminium sheath, at a certain distance from it and from each other..
