Internal Bus Expansion Module: Left Side OM757 Available for Import

Internal Bus Expansion Module: Left Side OM757 for Enhanced Network Assembly

Electrical Measurement Instruments
Manufacturer: DOLOMANT OJSC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Available Models

OM750 bus termination module Power supply module OM754 Power supply module OM755 Potential multiplication module "24/48V" OM759 Power supply module OM752

Description

The OM757 module is designed together with the OM756 module and the connection cable to divide the network node assembly into several separate assemblies with one common controller and is mounted on a DIN rail in the leftmost position of the assembly segment. The OM757 is also used to generate the internal bus supply voltage (FBUS) for the Bus Terminals. +5 V is generated from the 24 V DC voltage The module has terminals for potentials of the supply buses.

Specifications

Bus connection
1×RJ-45, female connector
Maximum distance between OM756 module and OM757 response module
5 ?
Transmission medium
UTP or STP Cat. 5 or 6 EIA/TIA-568-B
Power supply voltage
24 V DC (-15...+20%)
Maximum load current
2 ?
Voltage on the potential busbar
24 V DC (-15...+20%)
Maximum current on the potential busbar
10 ?
Insulation voltage
500 V (system/power supply)
Mean time between failures
2 300 000 ?
Weight
0.065 kg
Scope of application
Electric power, shipbuilding, oil and gas, metallurgy, utilities, railroads, and mining.
Mark
OM75701

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
