Integrated circuit 1892VM268

The 1892VM268 ELIoT chip is a system-on-chip ultra-low power microcontroller for control and navigation systems such as: industrial internet of things, smart sensors, trackers.CPU1 ARM Cortex-M33 core with support for floating point operations FPU, maximum clock frequency - 160 MHz; CPU0 ARM Cortex-M33 core, maximum clock frequency - 53 MHz; instruction cache size of 16 Kbytes for each CPU core; block supporting crypto algorithms of traffic encryption and metadata signing (Crypto Cell); digital part of GLONASS/GPS receiver; Quad SPI external memory interface; USB 2.0; SD 3.0/MMC 4.51 port; external static memory interface 16 bits, with support for LCD displays c interface type Intel 8080; CAN 2.0 port with support for CAN FD; 2 PWM controllers 8 channels; 4 GPIO ports 16 pins; timer block RTC, WDT, TIM; debug interface JTAG/SWD.
