Available for Import
Horizontal boring machining centre STC H 622
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Optionally, the machine can be equipped with various attachments (faceplate, milling heads, etc.)..
Technical Specifications
| Type of product according to PP RF 616 | Horizontal boring machines (universal, CNC, CNC) |
|---|---|
| Diameter of boring spindle | 110* mm |
| Table work surface size | 1100x1250 mm |
| Table load capacity | 15000 kg |
| Tool magazine capacity | 50* (40, 64, 100, 124) pc |
| Overall dimensions (width/length/height) | 4 500 / 6 900 / 4 200 mm |
| Machine weight | 18000 kg |
| Rated power of the spindle rotation drive | 28 kW |
| Maximum torque on spindle, Nm | pull-out 2050 |
| Maximum programmable movements | in x-axis (table transversely) 1300, 1600, 2000, 2500, 3100 mm |
| Working feedrates in X, Y, Z, W axes, mm/min. | 1...10000 mm |
| Rapid traverse speed in X, Y, Z, W axes; m/min | 12, 12, 8, 12 m |
| Maximum tool diameter | 125 mm |
| Maximum tool length | 400 mm |
| Maximum spindle speed | 3000 |
| Length | 6900 mm |
| Width | 4500 mm |
| Height | 4200 mm |
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
