Horizontal boring machining centre STC H 140K

Metal Machining Centres

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

Horizontal boring machining centre STC H 140

Horizontal boring machining centre model STC H 140K with cross-moving stand is designed for complex machining of body and base large-sized parts, including welded, made of ferrous and non-ferrous metals.
The machine with high dynamic characteristics (spindle speed Ø 130 mm up to 3000 rpm, speeds of fast movements up to 15 m/min) and reduction of machine weight to a level sufficient for cost-effective machining of parts.

Technical Specifications

Type of product according to PP RF 616	5-axis horizontal machining centers
Length	8000 mm
Width	6000 mm
Height	5200 mm
Machine type	Machining centre STC H 140K
Table work surface size	1250x1400; 1600x1800* 1800x2500; 2000x2500; 2900x3500 mm
Diameter of boring spindle	110; 130*; 150; 160 mm
Maximum spindle speed	1700; 2000; 2500*; 3000
Rated power of the spindle rotation drive	22; 28*; 39 kW
Maximum spindle torque, Nm:	1700; 2050; 55001700; 2050; 3500- milling - retractable nm
Maximum programmable movements	- in x-axis (table transversely) 3000; 4000; 6000; 8000; 12000 and more - in y-axis (spindle headstock vertically) 2000; 2500; 3000; 3500; 4000; 4500 - in z-axis (boring spindle) 710*; 1000 mm
Maximum programmable movements	- along the w axis (stand longitudinally) 1150; 1600*; 2000 - along the c axis (rotary table); deg 360 mm
Speed of fast movements in X, Y, Z, W axes	m/min 12 m
Maximum feed force in X/ Y/ Z/ W axes	kN 8 / 10 / 8 / 12
Tool magazine capacity	SBVVBG pc
Maximum tool diameter	125 mm
Maximum tool length, mm 400	400 mm
Machine weight	25000 kg
Table load capacity, kg	6 000; 12 000*; 40 000 kg
Working feed rate limits in X, Y, Z, W axes	mm/min 5 .... 6000 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
