High Voltage Power Supply SHVMP

Static Power Converters

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

The SHVMP series of high-voltage power supplies for server rack mounting includes models with positive and negative polarity with output voltage from 1kV to 60kV with power from 100W to 1200W. All models are equipped with a set of protections with adjustable thresholds and support three modes of operation: current, voltage and power regulation, which allows the devices to be used for a wide range of industrial and research applications.
FEATURES
Input power protection
Overload and short circuit protection
Output over/under voltage protection
Arc fault protection
Active power factor correction with 99% efficiency
Analogue interface with opto-coupling (DA-15)
Analogue interface compatible with Spellman interface (JBI STR 50)
Support for RS-232, RS-485, USB, GPIB, Ethernet digital interfaces
Intuitive user software
Production, support and service - RF

Specifications

Digital control interfaces RS-232; RS-485; USB; GPIB; Ethernet

Setting the output voltage/current Multi-turn potentiometer on the front panel

Safeguards By input power supply, undervoltage and overvoltage, output current exceeded, output power exceeded, output short circuit, output arc discharge, operating temperature exceeded

Instability of output current 0.01 %

Output current setting accuracy 0.05 %

Instability of output voltage when load changes 0.005 %

Instability of output voltage when input voltage changes 0.005 %

Output voltage setting accuracy 0.05 %

Output voltage adjustment 0 to Vout max

Polarity Positive, Negative or Customizable

Power supply voltage 195...245 V

Output voltage ripple 0.05 %

Output power 100...1200 W

Maximum output voltage 1000...60000 V

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
