Helical two-stage gearmotor 1??2?, 4??2?

Cylindrical two-stage gearmotor type 1MTs2C, 4MTs2C is a
electromechanical drive for general machine-building applications.
Special asynchronous three-phase squirrel cage motors are used for the equipment.
motors. The use of special motors of increased accuracy made it possible to mount
drive pinion directly on the motor shaft
The gearbox is designed according to the coaxial scheme with shafts in the vertical plane.
Cast iron gearbox housing is docked in the vertical plane with two cylindrical pins and bolts.
pins and bolts.
Gear gears of the gearmotor 1??2?-100? , 4??2?-100? are made with a meshing
Novikov gearing with modified original contour, other gearmotors with involute gear
gearing with original contour according to GOST 13755-81. For the production of gears
Novikov gears are made of 40X steel, which is improved to hardness HB 269...311.
Evolute gears are made of steel 25???, nitrocemented,
hardness of working p...
