Geophysical instruments and devices

Geophysical Instruments

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

The equipment is designed for geophysical research in the control of oil and gas fields development in order to assess the technical condition of production wells. Scope of application:- measurement of water-saturated porosity of rocks;- separation of gas-liquid and water-oil contact;- lithological dissection of section;- temperature measurement;- determination of temperature anomalies;- pressure measurement;- measurement of exposure dose rate of gamma radiation of rocks; - determination of intervals of fluid inflow into the well; - determination of the position of socket joints of tubing and casing pipes; - determination of perforation intervals; - binding of measured parameters by depth.

Specifications

Power consumption 1.5 W

Power supply voltage 75 V

Measuring range of absolute temperature values, 0C -10...120 °C

Limits of permissible basic absolute error, 0C -1...1

Thermal inertia index determined in water 3

Measuring range of absolute temperature values, 0C 0...120 °C

Measuring range of water-saturated porosity of rocks, % 1...40 %

Tolerance limits of basic relative error, % 2.3...4.2 %

Measuring range of water-saturated porosity of rocks, % 1...40 %

Tolerance limits of basic relative error, % 2.3...4.2 %

DER measurement range, A/kg (µR/h) 1...100

Supply current, mA 20

Supply voltage, V 60...75 V

Power, W 1.5 W

Length 2120...2481 m

Weight 10...47 kg

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
