FLEX ATX Motherboard for Compact Systems HN-DP1000T-D

Available for Import

FLEX ATX Motherboard HN-DP1000T-D for Compact Computing Solutions

Advanced Computing Devices

Manufacturer:MEGAPOLIS-TELECOM REGION LLC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

FLEX ATX format computer motherboard HN-DP1000T-D is designed for use in monoblocks and other small-sized computing systems. It has a full set of video interfaces (VGA, HDMI, DVI, DP). Two network interfaces: 1 RG-45 Ethernet POE 1Gb/s and 1 2.5Gb/s

Specifications

Power supply voltage

B1/B8 2100/900 MHz V

Operating temperature range

5...35 °C

Operating system support

Windows 10 64-bit, Windows 11 64-bit, Linux

Internal IO ports

1xATX_24P, 1xATX_8P, 2xCPU_FAN, 2x SYS_FAN, 1xF_PANEL, 1xF_AUDIO, 1xSPEAKER, 1xCOM, 1xeSPI, 2xF_USB with 2xUSB2.0 ports, 1xF_USB3.0 with 2xUSB3.0 ports, 1xF_Type-C 5Gb, 1xCLR_CMOS, 1xLVDS1 Full HD1080P, 1x LVDS2 QuadHD 2K 2560x1440, 1xINVERTER, 1xLCD_PWR,

Rear panel IO ports

1xPS/2, 2xUSB 2.0, 1xVGA, 1xDVI-I, 1xDP, 1xHDMI, 2xUSB 3.2 Gen2x1 10Gb, 1xRJ45 LAN 10/100/1000/2500Mbps, 1xRJ45 LAN 100/1000Mbps red with POE power (AT), 1xUSB 3.2 Gen1x1, 1xUSB Type-C 20Gb, 1xAudio jack (Line-in/Line-out/Mic-out)

PCI Slots

1xPCI Express X16 Gen 4.0/5.0, 1xPCI Express X1 Gen 3.0, 1xM2 PCI 3.0 Wi-Fi/BT

Sound

1x Realtek ALC897 high fidelity audio controller (HD audio)

Network interfaces

1x Realtek® RTL8125B 10/100/1000/2500Mbps WOL, 1x Intel®I211 100/1000Mbps Ethernet POE (AT)

Storage system

4xSATA 3.0 6Gb/s, 2xM.2 SSD 2242/2280 PCIe x4.0

Display

Intel® HD Graphics 1xVGA 1920x1080@60Hz, 1x DVI_I 1920x1080@60Hz, 1xDP 7680x4320@60Hz, 1xHDMI 4096x2160@60Hz

Memory

2xDDR4, <=3200 MHz, max 128GB or 2xDDR5 <=5600 MHz, max 128GB

Chipset

Intel® B660/760

Processor

Intel® Core™i3,i5,i7,i9/Pentium /Celeron 12th generation LGA1700 or Intel® Core™i3,i5,i7,i9 13th generation LGA1700.

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
