Fire-Resistant Flat Power Cable 660V AVVGng(A)-LS-As 2x2.5 for Safe Electrical Applications

Aluminium Power Cables 1kV

Manufacturer:TSVETLIT OJSC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Flat fire-resistant power cable with PVC insulation with low toxicity of combustion 1kV AVVGGng(A)-LSLTx 2x10 Power flat shielded cable with PVC insulation 660V AVVGE-P 2x6 Flat power cable with PVC insulation of reduced flammability 1kV AVVVGng(A)-P-As 2x2.5 Flat power cable with PVC insulation of reduced flammability 1kV AVVVGng(A)-P-As 3x10 Flat power cable with PVC insulation of reduced flammability 660V AVVVGng(A)-P 3x6

Description

Cable of flat form with a core made of heat-resistant aluminium-zirconium alloy with insulation and sheath made of polyvinylchloride plasticate of reduced fire hazard, not spreading combustion, with low smoke and gas emission. For laying, taking into account the volume of combustible load of cables, in internal electrical installations, as well as in buildings, structures and closed cable constructions.

Specifications

Mark

AVVG-Png(A)-LS-Ac

Core material

aluminum-zirconium alloy

Insulation material

PVC plasticate of reduced fire hazard, not spreading combustion, with low smoke and gas emission

Sheath material

PVC plasticate of reduced fire hazard

Calculated weight

64 kg

Filler material

interfacial space filler made of PVC plasticate of reduced fire hazard

Climatized version

UHL

Nominal voltage

660 V

Ambient temperature during cable operation

OT -50 to +50 °C

Number of cores

2 pcs

Core cross section

2.5 mm²

Cable thickness

5.25 mm

Cable width

8.1 mm

Fire hazard class according to GOST31565

P1b.8.2.2.2.2.

Longest permissible operating temperature of conductors

70 °C

Maximum permissible heating temperature of cable cores in overload mode

Flat grinder, Specialised grinder °C

Maximum heating temperature of cable cores at short circuit

160 °C

Maximum heating temperature of cable cores under the condition of non-fire in case of short circuit

350 °C

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
