Extended Anode Grounding Rod Type 1 (AZPr.PTM.1) for Corrosion Protection

Low-Voltage Electrical Panels

Manufacturer: PROMTEHMASTER LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Anodic long-distance earthing electrode type 2 (AZPr.PTM.2)

Description

Anode earth electrodes of extended type AZPr.PTM.1 are intended for use as low-soluble subsurface extended anode earth electrodes in installations of cathodic protection against corrosion of main pipelines and other underground steel structures, installation of current-sinking circuits. Type 1 - with working element made of electrically conductive polymer or other electrically conductive material (rubber filled with carbonaceous component; polyethylene filled with carbonaceous component; polyvinyl chloride filled with carbonaceous component), with nominal specific density of anode current not more than 50 mA/m.

Specifications

Type

Anodic earthing electrode of extended type 1 (AZP.PTM.1)

Length

1...600 mm

Outer diameter of the product (diameter of coke shell in protective braid)

36...100 mm

Outer diameter of the working element

1...80 mm

Material

Type 1 - with working element of electrically conductive polymer or other electrically conductive material
