Explosion-proof push-button control centre PWK-OEAP-X-5

PVK-OEAP-X-5 posts are designed for control of electric drives of machines and mechanisms, in stationary installations and on mobile means of land and sea transport, for control of electric parameters, as well as for signalling related to the mentioned electric drives or other electrical devices.
devices.
The posts are designed for operation in explosion-hazardous
areas of production, means of transport and storage of products
chemical, oil refining, gas and other industries.
industries.
The enclosure of the PBC post consists of a body and a cover (material: plastic). The cover is screwed to the casing with hexagon socket screws. At the customer's request, the cover can be fitted with Ex-components inside the shell.
Ex-components can be installed inside the shell on the cover: push-button elements with contact blocks of BKV type, providing switching of electric circuits,
measuring devices; switches; light indicators. In the case
cable glands are mounted in the housing. The enclosure is fixed with
brackets with holes.
