EG-DKU-04-232-024-U1-65-PSL, LED luminaire

LED luminaire for outdoor use, designed for illumination of class A highways, cantilever, landing size 50 mm, installed on lighting supports up to 30 m, has a wide light intensity curve, overall dimensions 710x212x87 mm, the body is made of anodised aluminium, the optical part is made of light-stabilised polycarbonate, operating voltage: 176-264V, frequency 50 Hz, power consumption 232 W, luminous flux 28070 Lm, colour temperature of choice 3000/4000/5000K, colour rendering index: Ra > 80, power factor: PF > 0.97, ripple factor less than 1%; protection class against electric shock 1, galvanic isolation, short-circuit and voltage drop protection, EMC compliant, degree of protection against environmental influences: IP65, climatic design U1, LED module material - foil aluminium with thickness not less than 1.5 mm and thermal conductivity not less than 2 W/m *K, operating life - 100 thousand hours, warranty period - 6 years.
