Dump truck 4590U1 on chassis Ural 73945-01;

Diesel Dump Trucks

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

A dump truck with three-sided (two-sided) unloading, designed for transporting bulk goods of national economy and agricultural products (grain, seed). One hydraulic cylinder, unloading angle on two sides - 45 degrees, back - 25...30 degrees. Dump body made of 09G2S steel has its own design features to keep working capacity and fulfil its functionality during the whole service life. The body is equipped with seals and components that ensure safety, reliability and convenience in operation.
The tipper body can be executed in two variants:
1. Board panels made of NEXT profile, which allows to carry universal cargoes,
2. lightweight, the panels of boards from M-profile, which allows to carry a larger volume of cargo.

Technical Specifications

Equipment	4590u1
Type	mtun332
Type of product according to PP RF 616	diesel dump trucks
Mark	-
Gross weight	27500 kg
Type of product according to PP RF 616	diesel dump trucks
Type of product according to PP RF 616	diesel dump trucks
Additional option	Installation of a removable overboard; installation of a dispenser (on the rear board for portion unloading); refinement of the body with seals for bulk cargo (grain. seeds. except rape. flax); installation of a frame awning with a winding device + platfor
locking mechanism	1) manually operated mechanical side locks. 2) for profile next version, the side locks can be hydraulic, operated by the driver from the vehicle cab (only for side discharge version).
Superstructure material	steel 09g2S... made in the form of profiled panels: profile next thickness of board panels 3 mm. floor decking 4 mm. m-profile thickness of board panels 2...3 mm. floor decking 3...4 mm.
Rear wall design	The tailgate can be made in three versions: 1) fixed. rigidly fixed to the body; 2) one-piece tailgate opens to the side; 3) 300mm high top part on the lower linkage. middle part is fixed. 850mm high bottom part on the upper linkage.
Side panel design	For the tipper body made of next profile, the hinging of the side boards can be made in 3 (three) versions: 1) upper board - with upper hinging. lower board - with lower hinging. height of the lower board 500mm (book version. next profile); 2) side boards
Wheelbase	4905+1440 mm
Base chassis	URAL 73945-01
Body volume	5500x2340x1500 (1650) mm
Body volume	17.8 m[3] 22 m[3)
Payload	12.8 t (13.28 t )

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
