Dual Cross Switch Type R65 Model 1/9 Project 2843.00.000-01 Available for Import

Dual Cross Switch Type R65 Model 1/9 for Efficient Track Switching

Railway Track Components
Manufacturer: MSZ OJSC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

Double crossing switch type ?65 of mark 1/9 on reinforced concrete bars is designed for transfer of rolling stock from one track to another or for passing along the straight direction. Sharp crossing of welded construction - rail ends are welded to the core made of high-manganese steel. Blunt cross member - solid cast from high manganese steel.

The counter rail is not connected to the track rail. All pads have high flanges. The shackles and frame rails are HFI hardened.

Specifications

Type of product according to PP RF 616
Track equipment and devices and their parts
Type
?65
Cross type by angle
1/9
Save Your Time

Share your requirements for a quick response!

Instant response in 15 minutes
Best wholesale prices guaranteed
Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
