Drilling rig UBG-S-30 "Berkut"

UBG-S-30 "Berkut" is a multifunctional tracked drilling rig designed for drilling engineering wells in rocks of I-XII categories.
Thanks to its high technical performance, the rig is versatile and provides a wide range of tasks in the most difficult conditions.
Despite its small size and transport without a trawl, the rig has the best performance in its class:
-torque 40,500 Nm
-feed force 10,000 kg
-spinner feed stroke 5,000 mm.
-mass 10,000 kg
Purpose
UBG-S-30 "BERKUT" is used for drilling boreholes for piles and sheet pile fences, supports of power lines and gas and oil pipelines, drilling of rock with large diameter, geological exploration at placer gold deposits, water dewatering, engineering and geological surveys, drilling of water wells, screw piling and other works.
Drilling methods
-auger
-post
-pneumatic percussion
-with backwashing
-with flushing
-purging
-channel-impact
