Double rack CNC lathe-carousel machine of 1M532F4 model and its modifications

Multi-Function Metal Machines

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Available Models

VBL1600 CNC Single Standing Centre Centre Lathe VBL2000 CNC Single Standing Centre Centre Lathe Double column CNC lathe-carousel machine of model 1M540F4 CNC

The machine lathe-carousel two-stand CNC model 1M532F4 CNC is designed for roughing and finishing machining of parts made of cast iron, steel, non-ferrous metals and their alloys, namely: processing of internal, external and end surfaces of rotation of simple and complex shapes, as well as cutting threads or screw grooves on surfaces coaxial to the axis of rotation of the faceplate

Technical Specifications

Largest diameter of the workpiece to be machined	3200 mm
Maximum height of the workpiece to be machined	1600 mm
Maximum weight of the workpiece to be machined	25000 kg
Table face diameter	2800 mm
Maximum torque on the faceplate, kNm	125
Power output of the electric motor of the main motion of the faceplate	2x40 kW
Maximum cross member displacement	1200 mm
Crossbar travel speed, mm/min	400

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
