Detector of explosives with built-in search radiometer DIANON
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Description
"Dianon" is a new unique development of TSNK company, which combines two products at once: a portable fast-acting highly sensitive detector, which allows to detect and identify explosives both in the form of vapours and particles (traces) and a search radiometer, which allows to detect and localise sources of ionising gamma radiation.
The built-in radiometer allows estimation of the radiation dose rate, indication of the maximum value of the dose rate during operation, as well as indication of the accumulated radiation dose during operation of the device. The working exposure time of the Dianon radiometer is only 1 second, which is an undeniable advantage of this product over competitors.
The instrument is based on advanced technology, which is based on the principle of non-linear dependence of ion mobility on electric field strength. The corona discharge principle is used for ionisation of sample molecules.
The device does not require special
The built-in radiometer allows estimation of the radiation dose rate, indication of the maximum value of the dose rate during operation, as well as indication of the accumulated radiation dose during operation of the device. The working exposure time of the Dianon radiometer is only 1 second, which is an undeniable advantage of this product over competitors.
The instrument is based on advanced technology, which is based on the principle of non-linear dependence of ion mobility on electric field strength. The corona discharge principle is used for ionisation of sample molecules.
The device does not require special
Specifications
Sensitivity of radiation registration with energy 662kEv (Cs-137) by the built-in detector, imp./(µR/hour) (in radiometer mode)
1
Carrier gas
Not required
Exposure dose rate measurement range, mR/h (in radiometer mode)
0÷50
Measurement error of exposure dose rate in the range 30..3000kEV, % (in radiometer mode)
less than 30 %
Energy range of registered photon radiation, keV (in radiometer mode)
30 to 3000
Storage conditions
Temperature : -30°C...+50°C Relative humidity 98% (at +25°C)
Working conditions
Temperature - -20°C...+50°C Relative humidity 95% (at +25°C)
Power supply
less than 15 watts (Search and Identification modes), less than 22 watts (Wipe mode) W
Overall dimensions of the detector, mm (L x W x H)
400x160x110 mm
Weight with battery installed
2.5 kg
"Hot" battery replacement
possible
Probability of false alarms
Less than 1 per cent (in Identification and Wipe modes) %
Saving analysis history in the detector memory
Check: date, time, type of detected material
Quiet mode
Got it
Battery discharge indication
Yes, display on display
BB detection warning signal
Audio and visual indication; In "Identification" and "Wipe" modes - indication on the display of the type of the detected substance
Possibility of connection to an external computer (PC, Mac)
Ethernet or Wi-Fi. No special software installation required.
Display
Colour, touch (resistive) 4.3"
Battery operation time (installed on the device)
240 min (without heating module) 120 min (with heating module)
Calibration
Automatic
Detection time
In "Search" mode, less than 2 seconds; In "Identification" and "Wipe" modes, less than 8 seconds.
Types of substances to be detected
TNT, TEN*, RDX* (hexogen), DNT, nitroglycerine, ammonium nitrate + diesel fuel mixture* (ANFO), EGDN, HMX*, Tetril*, gunpowder mixture*, ammonium nitrate, urea nitrate and others.
Threshold sensitivity to TNT (at temperature 20°C and humidity 80% )
10-14 g/cm3 (1 ppt) - in vapour analysis mode, 100 picograms - in trace analysis mode
Ionisation source
Corona discharge
Technology
Ion mobility incremental ion mobility spectrometry (FAIMS)
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
