Cultivator KSU-6PS

Cultivator for continuous tillage, semi-trailed. Designed for continuous loosening of soil up to 25 cm, destruction of weed vegetation. It consists of:
- three welded frames (centre frame, two wings), to the brackets of which the working tools are attached, directly interacting with the soil. The method of protection of the working tools racks from overloading is double - shear bolts and springs automatically returning the working tools to the working position after removing the overload. Number of working tools - 21 pcs.
- truss, which is a welded structure, to which the centre frame, chassis and trailing device are attached.
- hydroficated chassis.
- hitching device (welded frame structure with forged rotating shackle and damping device).
To adjust the cultivation depth, a double roller made of U-shaped profile is installed at the rear of the cultivator, which additionally loosens the soil and by means of which the cultivation depth is adjusted. For furrowing the furrows from the working tines...
