Compact Sliding Gate Valves with Expanding Shutoff DN150-500

Available for Import

Compact Sliding Gate Valves with Expanding Shutoff for Flow Control

Gate Valves

Manufacturer: TYAZHPROMAMMATURA OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Shiber gate valves compact with expanding gate are used as a shut-off device for shutting off the flow of working medium in oil - and oil product pipelines. Nominal diameter DN 150, 200, 250, 300, 350, 400, 500. Nominal pressure PN 1.6, 2.5, 4.0, 6.3MPa.

Seal tightness - class A (GOST 9544-2015). Manufacturing and delivery according to:TU 3741-005-37876514-2015 Pipeline connection: flanged and welded. Climatic execution: temperate (ambient temperature from -40 0C to +400C); cold (ambient temperature from -600?

to +400?); Temperature of transported medium: for commercial oil: from -15°C to +80°C; for oil products: from -35°C to +60°C. Gate valves are manufactured: with manual operation and under electric drive. Service life is not less than 30 years.

Specifications

Airtightness class

class A

Nominal pressure

1,6; 2,5; 4,0; 6,3 MPa

Nominal diameter

150 mm

Service life

30 years

Connection type

Flanged and welded

Save Your Time

Share your requirements for a quick response!

Looking for

Quantity

Your mobile

Instant response in 15 minutes

Best wholesale prices guaranteed

Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
