Available for Import

Cabinets of Tekon software and hardware complexes of SHKA-P type

Low-Voltage Electrical Panels

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

SHKA-P complete automation cabinets (power supply cabinets) can be used in various industries, including in explosion and fire hazardous production outside of explosion and fire hazardous areas:
- in the power industry, including power systems, power plants, power facilities, industrial and equivalent enterprises, household consumers and other energy consuming or energy supplying enterprises and organisations;
- in the oil and gas, chemical and petrochemical industries;
- in metallurgical and coke-chemical industries;
- in mechanical engineering, woodworking and other industries.

Specifications

Type Low-voltage complete automation cabinet SHKA-P

Climatic version UHL4 and UHL1 according to GOST 15150-69

Temperature class without ventilation: + 1 to + 50 C with ventilation: + 1 to + 60 C

Degree of protection IP54 or IP20

Housing material made in the form of a metal frame made of a specialized profile with collapsible side walls, roof, with or without plinth, front and rear doors

Material of manufacture The front door can be made of solid metal, metal with a viewing window or solid glass.

Color RAL 7035

Explosion protection no

Height 2000 mm

Width 800...1200 mm

Type of explosion protection no

Modules no

Material Metal case

Current capacity 2.5.1.4 Emission of harmonic components of the consumed current from the AC electrical network must meet the norms of emission of harmonic components of the consumed current, established in GOST 30804.3.2-2013 (section 7 class A)

Size; mm 800-1200/2000/400-800 mm

Mark TECON

Frequency SBVVBG

Equipment Uninterruptible power supplies, Cabinets, Power supplies, Power switching devices

Assignment 2.3.1 The SHKA shall provide the following main functions: ? constant round-the-clock operation in all modes of normal operation; ? control of technological parameters and signaling of their deviations; ? remote control of equipment

Length 2000 mm

Degree of protection against external influences 2.7.1Nominal operating values of mechanical external influencing factors for the SHKA shall comply with GOST 17516.1-90 for mechanical design group M13 or M 6 (to be specified in the ToR)

By explosion protection no

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
