Block automated power station of container type BAEKT 512.2

1.Technical description
Rated power, kW - 512 kW
Rated voltage - 0,4 kV
Output current type - AC, three-phase
Rated frequency of output voltage, Hz - 50±1
Automation degree according to GOST 33105-2014 - 2
Weight, kgNo more than 20 000
Overall dimensions, not more than 12,0 x 2,4 x 2,7 m.
Electricity quality standards shall comply with GOST 32144-2013.

2.1Destination requirements
2.1.1General requirements to BAECT.
2.1.1.1 BAECT provides backup power supply to consumers of the product in case of main power supply failure at two mutually redundant inputs and is designed to:
providing the consumer with guaranteed power supply, by generating electricity of quality not lower than GOST 32144-2013;
control of the switching equipment of the DGU.
2.1.1.2BAECT is designed and manufactured in accordance with the following requirements:
GOST 12.2.007.0-75; GOST P 55005-2012;
current rules of use...
