BDM-7x2PT discator

Disc harrow. Semi-trailed disc tillage implement. Consists of:
-three welded frames (central, two wings), with welded sleeves, in which the working tools are installed with the possibility of rotation at a limited angle. The working element is a rigid column, a bearing unit and a spherical disc, which is directly the working element that cultivates the soil.
- truss, which is a welded structure to which the centre frame, hydraulic cylinders for lifting the wings, undercarriage, trailed implement are attached.
- trailer hitch.
- hydroficated chassis.
The implement has two rows of working tools and one row of additional wavy discs.
For levelling the cultivated soil, a leveller (roller) is hinged to the frame at the rear. The implement can be equipped with the following types of rollers: tubular, spiral or chevron rollers. The depth of cultivation can be adjusted by means of the roller. The width of the cultivated strip is 7.2m.
