Ball shut-off valve ATEK.491284.157

Ball Valves

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

The steel ball valve is designed for hermetic separation (normally closed valve - NC) or connection (normally open valve - NO) of two sections of the pipeline on commands of control and protection systems. The valve is controlled by electric actuator or manual actuator installed on the valve. The tightness of the valve is class A of GOST 9544. The valve is hermetically sealed in relation to the external environment. Connection to pipelines is welded. Welding is carried out by means of adapters on mating flanges. The presence of mating flanges with adapters, which are elements of the design, provides a quick removal of the valve without cutting from the pipelines.

Technical Specifications

Type of product according to PP RF 616	Shut-off valves for process control (gate valves, cocks, stop valves, disk gates and other fittings)
Direction of the environment	Bilateral
Operating medium	Natural gas
Temperature, up to	150 °C
Nominal pressure, up to	2.5 MPa
Nominal diameter	32 mm
Full bore	Full bore

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
