Automated welding line of LDK-5 type

Electric Welding Machines

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

The line of welding of double branch frames, hereinafter referred to as "line", is designed for the manufacture of flat frames up to 360 mm wide from longitudinal wires with a diameter of 4-5 mm with automatic feeding of cross wires with a diameter of 3-5 mm from coils.

The line is used at construction industry enterprises. The line is designed for operation in temperate climate conditions. Design and category UHL4.

The line consists of: coil holders, welding machine, bundler, cross feeder. The cross wire coil holder is installed on the workshop foundation.

The coil holder is designed with a vertical axis of rotation and is intended for installation of reinforcing steel coils of different diameters and weights.

The welding machine is designed for welding of the frame. It consists of a bed, on which are fixed all the main components of the machine: electrode drive unit, the mechanism for feeding longitudinal rods, the mechanism for cutting and feeding the cross wire under the electrodes, pneumatic equipment, transformer. The main ...

Technical Specifications

Type of product according to PP RF 616	Arc welding equipment
Power	80 kW
Operating voltage	380 V
Mark	LDK-5
Mains frequency	SBVVBG
Grid width	400 mm
Height	1600 mm
Width	3850 mm
Length	11140 mm
Weight	2000 kg

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
