Astra-RI-M RR radio expander

Fire Safety Devices

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

Radio expander "Astra-RI-M RR" is designed to receive signals from registered detectors (sensors) over the radio channel 433 MHz and output to the built-in relays and the interface line RS-485. 3 relays and 1 output "open collector".
Three modes of operation:
- autonomous operation as a receiving device with support for 48 radio devices of different types,
- extender of addressable wireless zones as part of the Astra-RI-M system with Astra Pro series PPKOP with support for up to 192 radio devices of different types,
- repeater to increase the range of radio network coverage.

Specifications

Outdoor radio range in repeater mode 1500 m

Power in transmission mode, not more than 10 mW

Power supply voltage 10...28 V

Consumption current at 12 V, not more 1 A

Overall dimensions, mm 136x86x38 mm

Type of communication line with child devices Radio channel

Main and backup power supply control inputs In stock

Number of programmable analog inputs / outputs type OK 1 pc

Signal relay outputs 3 pc

Operating temperature -10...55 °C

Radio operating frequency, MHz literature 1 - 433.42

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
