Anode MINADAGS ER-6

Low-Voltage Electrical Panels

Manufacturer:

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Key Highlights

Made in Russia - engineered for durability
Suitable for challenging environments
Lower cost of ownership than European alternatives
Bulk orders available with volume discounts
Documentation and customs clearance assistance provided

Description

Extended flexible low-soluble anode earth electrodes (hereinafter - PA) for application in the system of current-pumping anode earths of installations of cathodic protection of metal structures and constructions against underground corrosion in aqueous media. PAs provide long-term, uninterrupted and efficient flow of protective current from the cathodic protection station through the ground to the protected structure. PAs are designed for operation in soils with any specific electrical resistance, especially in soils with high specific electrical resistance (more than 100 Ohm-m). In soils with low resistivity (less than 100 Ohm-m), double-layer PAs with current-carrying sheaths are used, as well as combinations of PAs with distributed or concentrated anode earth electrodes.

Specifications

Climatic version -, ?

Type ER-6

Tinning of the copper core of the operating element and the lead cable - non-tinned core; l - tinned core

Cross-section of copper conductor of the operating element and supply cable, mm² 10, 16, 25, 35, 50

Nominal outer diameter of the working element by electrically conductive polymer sheath for "P"-polyolefin sheathing 14.7mm, 15.8mm, 17.6mm, 18.4mm, 20.1mm, 18.7mm, 19.8mm, 21.6mm, 22.4mm, 24.1mm

Nominal outer diameter of the working element by electrically conductive polymer sheath for sheath "E"- of rubber 21mm, 36mm, 50mm, 90mm

Working element length 5...600 m

Reinforced design of the working element construction - without additional reinforcement; RS - reinforced core: copper core is reinforced with para-aramid threads.

Material of the backfill containment shell (only for versions with K, KMA backfill) abrasion resistant moisture permeable fabric

Presence and type of electrically conductive carbon backfill (activator) - without electrically conductive backfill; C - carbon backfill; CMA - coke-mineral backfill

Design and method of placement E - extended, placed in the ground along the protected structure

Conditions of use P - subsurface anode

Material of the electrically conductive sheath of the operating element E - electrically conductive carbon-filled rubber (elastomer); P - carbon-filled electrically conductive polyolefin (thermo- or reactoplastic).

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
