Air-cooled gas apparatus Aisberg 25,0-B1-B1-V011T/6-2-12-C

Parameter name Parameter value
Appliance typeBlock-modular
Apparatus group according to GOST 54803-20171
Working environment group according to ?? ?? 032/20131
Category of equipment according to ?? ?? 032/20134th
Volume of pipe space, m3 (capacity) section/apparatus1,13/ 2,26
Maximum mass of filled medium, kg section/apparatus 130/2 260
Design pressure, MPa (kgf/cm2)22,05 (206,49)
Design wall temperature, ?C130
Minimum permissible negative ambient air temperature, ??Minus 38
Name of working mediumNatural gas
Material designB1
Basic materialSteel 09G2S-8 GOST 5520-89
Coefficient of finning of pipes, ?20
Climatic execution GOST 15150UHL 1
Drive typeDirect
Electric motor typeVAB 225 SC12AVF B UHL1 (Explosion-proof - ExdllVT4)
Electric motor rated power, vW11
Synchronous part of electric motor rotation, rpm.500
Number of drives in the apparatus, pcs6
Wheel type RK25K3 UHL 1
Wheel diameter, mm2 500...
