Air conditioner PE KV.667413.002 TU

Car air conditioner (AC) is designed to maintain the specified parameters of microclimate in the premises of the passenger car in accordance with the requirements of sanitary rules SP 2.5.3650. The A/C is used on newly manufactured passenger cars, on modernised passenger cars, on passenger cars under repair. The AC can be manufactured with different variants of accessories that do not change the basic parameters and characteristics stated in these specifications. Name of consumer parameter Value1 Cooling capacity, kW* 22 5 %2 Maximum power consumption in "Cooling" mode, kW, not more than 12,53 Maximum supply air flow rate, m3/hour 4000+8004 Outdoor air flow rate, m3/hour 016005 Excess static pressure of supply air at the outlet of AH, Pa** 300 306 Total heat capacity of liquid calorifiers, kW, not less*** 207 Total heat capacity of electric calorifiers, kW **** 6 12 %8 Weight of AH in the filled condition 800 kg
