1/11 P65 type R65 STREET TRANSFER (project 2745.00.000/01)
Manufacturer:
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Key Highlights
- Made in Russia - engineered for durability
- Suitable for challenging environments
- Lower cost of ownership than European alternatives
- Bulk orders available with volume discounts
- Documentation and customs clearance assistance provided
Description
The track crossing of type R65 mark 1/11 on wooden bars is designed for transfer of rolling stock from one track to another. The arrow has a rotary shank. Frame rails are fixed on pads with cushions by means of stops. Pads with pads of welded construction are used. The crossarm is prefabricated - the core made of high manganese steel is bolted together with rolled rail whiskers. The R65 type R65 grade 1/11 type railway crossing of project 2745.00.000/01 is manufactured in the following versions: 2745.00.000 - right-handed; 2745.00.000-01 - left-handed.
Specifications
View in the direction of a side or crossing track
Left, right
Rail type
?65
Cross brand
1/11
Arrow design
With rotating sharps
View
Single
Cross type by angle
Spicy
Type of product according to PP RF 616
Track equipment and devices and their parts
Type of single transfer
Ordinary
Cross type by construction
Team
Type of timber
wooden
Type
?65
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
