Vacuum Gauges for Hydrocarbon Gas Measurement VP3A-Ks

Vacuum Gauges for Hydrocarbon Gas Measurement VP3A-Ks

Brand: MANOTOMЬ

$42 - $180 USD

MOQ: 50 pieces

Key Features

Measuring range: -1 to 0... kgf/cm2

Housing material: stainless steel

Accuracy class: 1,5; 1,0

Design options: radial socket without flange, radial socket with rear flange, axial socket without flange, axial socket with rear flange, axial socket with front flange, devices with protection class IP 53 are only available with radial socket without flange.

Supplier Information

MANOTOM OJSC

🇷🇺 📦 🏭 🛡️

View All Products

Quick Inquiry

More from MANOTOMЬ

Corrosion-Resistant Manometers for Measuring Overpressure and Vacuum - DA2010SgKs

$90-$300

Stainless Steel Manometer M-3VUKs 1.5 for Pressure Measurement

$15-$60

Digital Pressure Gauge DМ5002М-JKI 100MM

$90-$360

Pressure Gauge for Measuring Excess Pressure MP3A-U

$15-$60

Pressure and Vacuum Gauges MVP4-U

$15-$60

Pressure Gauge MP3A-Ks 1.5 for Measuring Overpressure and Vacuum

$15-$60

Manometers for Measuring Pressure Manotom M-2VU

$9-$36

Vacuum Pressure Gauge with Signal Display DV2005Cг

$90-$360

Vacuum Gauge Manometer V-3VU for Measuring Pressure

$15-$60

Connection Sleeve for Measurement Instruments - KS Model

$9-$36

Vacuum Pressure Gauge DW2005C1Ex for Hazardous Areas

$90-$300

Pressure Gauges DM5010Cg0Ex - Explosion-Proof Indicator

$90-$300

Marine Vacuum Pressure Gauges for Liquids and Gases

$90-$300

Corrosion-Resistant Pressure Gauges MP3A-Ks

$30-$180

Vacuum Pressure Gauge MVP4A-U for Gas and Liquid Measurement

$15-$60

Description

Designed for measuring vacuum pressure of hydrocarbon gas and water-gas-oil emulsion with the content of hydrogen sulphide (H2S) and carbon dioxide (CO2) up to 25 % by volume each, inorganic salts and paraffin up to 10 % by weight.

Specifications

Measuring range

-1 to 0... kgf/cm2

Housing material

stainless steel

Accuracy class

1,5; 1,0

Design options

radial socket without flange, radial socket with rear flange, axial socket without flange, axial socket with rear flange, axial socket with front flange, devices with protection class IP 53 are only available with radial socket without flange.

Inspection interval

2 kVAr

Climatic version

UHL1

Warranty period

3 kVAr

Fitting threads

M20x1,5-8g; K1/2; G1/2-B, K1/2 (1/2NPT); devices with protection degree IP 53 are produced only with connection thread M20x1,5-8g.

Body diameter

100 mm

Degree of protection

IP53 ( optional IP 54; IP65)
