Turbine flowmeter-counter RVSH-TA-10-U4

Flow meters of RVSH-TA type are designed for commercial and on-farm metering of quantity (volume) and flow in the range from 0,08 to 1900 m3/h of Newtonian liquids with kinematic viscosity from 0,6 to 300 mm2/s (cSt), temperature from minus 50 to plus 250 °?, pressure from 0,4 to 40 MPa.
According to the operating conditions flow meters are designed for use in stationary installations, on land mobile and portable means of refuelling and pumping during their operation on site, as well as at facilities where their use is possible according to the operating conditions.
Field of application: commercial and on-farm accounting in power, chemical, oil, oil refining industries and other spheres.
Relative error tolerance limits: ±0,25; ±0,50; ±1,00%.
