Tent of other textile fabrics Tactics-5

Frame tent Tactics-5. Used at temperatures from -40 ° C to +50 ° C.
Roof of PVC fabric 630-650 g/m2, side and end walls of tarpaulin with SCPV impregnation density of 540 g/m2.
Overall dimensions of the tent: length - 340 cm, width - 400 cm, side wall height - 160 cm, tent ridge height - 230 cm, area - 13.6 square metres. The tent has one entrance with a vestibule, a double-sloped roof, inner and outer walls. The entrance of the tent is closed with a flap and fastened with plastic pins and a metal zip. There is one hole in the roof with a flap for the stove pipe outlet. Chimney flap made of fireproof fabric or steel sheet for the outlet of the stove pipe. Two windows with mosquito nets on the rear end wall. The window openings are covered with a flexible PVC film and a light-protective curtain with a metal zip. The frame of the tent is made of profiled steel pipe with anti-corrosion protective coating.
The frame links are fixed in the adapters with thumbscrews DIN316..
