REM2-NT22 Relay Module 230V AC, Cat. No. 706 031

Available for Import

REM2-NT22 Relay Module 230V AC for Reliable Switching Applications

Intermediate Control Relays

Manufacturer:HAKEL OJSC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Relay module REM2-NT22 230AC, RBNM.647611.001TU represents two independent switching relays with LED indication of control voltage presence (switched state). The input and outputs of the module are galvanically isolated. The module allows switching at a maximum switching circuit voltage of 250 V AC.

The maximum continuous load current is at least 6 A. Rated control voltage is 230 V AC. The device is made in a plastic housing of protection class IP20.

The device is mounted on a 35 mm DIN-rail by means of a special latch on the rear side of the case.

Specifications

Maximum switched current in the load

6 A

Number of switchable contacts

2 pcs

Relay release time

0.008

Relay operation time

0.005

Operating temperature range

(40);60

Rated control voltage, AC

230 V

Method of attachment

DIN 35 mm rail lock

Weight

40 year

Size, WxWxH

106.4?100?7.4 mm
