Available for ImportRegulating Diaphragm Valve TD27087 DN 15 for Nuclear Safety Applications
Manufacturer:Znamia Truda OJSC
Price:Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
Designed for installation as a regulating device in normal operation and safety systems of nuclear power plants (NPPs) with VVER reactors.
Supplied domestically and for export, including countries with tropical climates..
Supplied domestically and for export, including countries with tropical climates..
Specifications
Operating medium
feed water, steam, inert gas; for stainless steel valves - all media according to np-068-05, except pulp;
Pressure, Rp
Pp 2.5 mpa (25 kgf/cm²), 4.0 mpa (40 kgf/cm²)
Operating medium temperature
max 250 °C
Pipeline connection
Welded
Housing material
08x18n10t, steel 20
Stem seal
bellows
Setting position
any
Valve control
manual, via gearbox, via articulated coupling
Media flow direction
on and under the plunger
Throughput characteristic
equal
Classification designation of the valve
3ciiiw per np-068-05
Seismic resistance category
ii per np-031-01
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
