R65 Type Switch Mark 1/11 for Railway Track Switching

Available for Import

R65 Type Switch Mark 1/11 for Efficient Railway Track Switching

Wide Gauge Track Switches

Manufacturer: MSZ OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The R65 type track switch of 1/11 grade is designed for transferring rolling stock from one track to another. In the switch is used: flexible shackles with welded rails. Crossing with a continuous rolling surface with a flexible-turn core.

The shackles, core rails and whiskers are HFI hardened. Frame rails, curve rails made of OT 350 category rails. The R65 type R65 grade 1/11 switches of project 2561.00.000-12/13 are manufactured in the following versions: 2561.00.000-12 - right-handed; 2561.00.000-13 - left.

Specifications

Cross type by construction

Team

View in the direction of a side or crossing track

Left, right

Rail type

?65

Cross brand

1/11

Arrow design

With flexible sharps

Type of single transfer

Ordinary

View

Single

Cross type by angle

Spicy

Type of product according to PP RF 616

Track equipment and devices and their parts

Type of timber

wooden

Save Your Time

Share your requirements for a quick response!

Looking for

Quantity

Your mobile

Instant response in 15 minutes

Best wholesale prices guaranteed

Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
