Protection device against impulse overvoltages RST 2BS 12/90/2 R, cat.no.402 515.

UZIP series RST 2BS */90/2 R, TU 3428-002-79740390-2007 are designed to protect equipment on circuits in which it is inadmissible to introduce additional resistance, from impulse overvoltages (lightning protection, protection from electrostatic discharges, etc.) within 1 - 2 lightning protection zones in accordance with GOST R IEC 62305-1-2010.Produced for rated operating voltage Uo = 12-24 V DC, rated current IL = 2 A. Data transmission speed up to 10 Mbit/s.Capable of passing the rated discharge current In (8/20)= 5 kA; ITotal (8/20)=10 kA.The devices are placed in a 7,4 mm thick case for installation on a DIN-rail 35 mm. Number of protected conductor pairs 2.
