Laboratory Setup for Research on Wideband Transformer (EE-SHTRR) Purpose/Applications

Study of various circuits and modes of DC voltage and current stabilisers. Determination of basic parameters and characteristics of parametric and integral stabilisers under variation of input voltage and load parameters. Study of characteristics of single-phase bridge rectifier and smoothing filter. List of works performed on the training stand: - Study of transformer at harmonic influence - Study of transformer at pulse influence - Study of single-phase bridge rectifier operation - Study of transformer operation with rectifier - Study of single-phase bridge rectifier
