IT14-GTD-110 Vibration Monitoring and Control System for Continuous Diagnostics

Measurement and Control Devices

Manufacturer: IT LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The IT14 monitoring, control and diagnostic system is designed for continuous measurement, storage and analysis of absolute and relative vibration parameters, distance (linear displacement, rotor warp, slope), shaft speed, temperature, current, voltage, electrical resistance and charge.

Specifications

Measuring range of vibration velocity harmonic amplitude, mm/sec

0.14...141

Operating frequency range of measurements of vibration velocity RMS and amplitude of harmonic components of vibration velocity

5...1000

Vibration displacement range, µm

0...2000

Non-uniformity of frequency response when measuring vibration displacement magnitude and vibration displacement harmonic amplitu

-5...5 %

Limits of permissible basic absolute error of the system when measuring the frequency of harmonic components of vibration veloci

-0.1...0.1

Measuring range of "rotor curvature" value, µm

6...2000

Operating frequency range of "rotor curvature" measurements

0.02...10

Unevenness of the frequency response when measuring the "rotor warp" value

-5...5 %

Slope measurement range, mm/m

-4...4

Tolerance limits of the basic reduced error of the system when measuring slope

-2...2 %

Measurement range of AC voltage frequency

0.01...10000

Measuring range of shaft speed

0.6...50000

Measurement range of AC voltage amplitude measurements

-10...10 V

Operating frequency range of AC voltage measurements

5...1000

Limits of permissible basic reduced error of the system when measuring electrical resistance

-0.2...0.2 %

Limits of permissible basic reduced error of the system when converting a digital signal into a unified current sig

-0.5...0.5 %

Charge measurement range, pCal

-500...10000

Unevenness of frequency response in charge measurement

-5...5 %

Limits of permissible additional relative error of the system when measuring vibration displacement magnitude, harmonic amplitud

-10...10 %

Ambient air temperature

-18...28 °C

Ambient air humidity

80 %

Power consumption when all system components are switched on at the same time

SBVVBG

The system provides processing of discrete signals on inputs of "dry contact" type with the following characteristics, maximum n

30 V

Maximum current of closed input contacts, mA

Average MTBF

50000

Assigned service life, years

Average time to restore serviceability

0.5

The system is resistant to the impact of a single earthquake of intensity

8 points

Type of product according to PP RF 616

Instruments and other instruments for measurement, control and testing

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
