General Purpose Fuse PPN-35 UHL3 125A, Dimension 1, IP00 (ET)

Available for Import

General Purpose Fuse PPN-35 UHL3 125A for Industrial Electrical Equipment Protection

Low Voltage Fuses

Manufacturer: ELECTROTECHNIC CJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Fuse PPN-35 UHL3 200A, gabarit 1, IP00 (ET) Fuse PPN-35 UHL3 100A, gabarit 1, IP00 (ET) Fuse PPN-35 UHL3 250A, gabarit 1, IP00 (ET) Fuse PPN-35 UHL3 80A, gabarit 1, IP00 (ET) Fuse PPN-35 UHL3 160A, gabarit 1, IP00 (ET)

Fuse PPN-35 UHL3 63A, gabarit 1, IP00 (ET)

Description

The PPN series fuses equipped with current-limiting fusible links of general purpose type gG are designed to protect electrical equipment of industrial installations of three-phase alternating current electrical networks with rated voltage up to 440V with frequency 50Hz and DC circuits with rated voltage 220V inclusive at overloads and short circuits.

Specifications

Current strength

125 A

Designation

PPN-35 UHL3

Voltage

440 V

Overall dimensions

135x48x62 mm

Item

ET522693

Power losses

12.2 W

Save Your Time

Share your requirements for a quick response!

Looking for

Quantity

Your mobile

Instant response in 15 minutes

Best wholesale prices guaranteed

Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
