Disc Varistor 40V 1.0kA (8/20) - Protection for Electrical Circuits

Manufacturer: HAKEL OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

VR14D680K - varistor of KVS series, 40 V, 1.0 kA (8/20), zinc-oxide, disc-shaped with unidirectional (radial) wire leads, protected, uninsulated.

Classification rated voltage at 1 mA current

68 V

Maximum AC operating voltage

40 V

Maximum continuous operating voltage

56 V

Permissible amplitude of a single current pulse (8/20 µs)

1000 A

Maximum pulse energy (2 ms)

12.2

Operating temperature range

-60...85 °C

Maximum disk diameter

17 mm

Maximum disk thickness

8 mm
